48000 BTU Quad Zone Mini Split Air Conditioner - Heat Pump - SENA/48HF/Q

Senville

MSRP $USD: $4,799.99
$4,399.99
(You save $400.00 )
You may be eligible for up to $10,000 in rebates. Check Availability
Senville 48000 BTU Quad Zone Mini Split Air Conditioner - Heat Pump - SENA/48HF/Q
SKU:
SENA-48HF-Q12121212
UPC:
893088008378
Availability:
Ships in 2 to 3 business days
Adding to cart… The item has been added

Product Overview

Senville · AURA Series

SENA-48HF/Q Quad-Zone Mini Split and Heat Pump

48,000 BTU of independent comfort across four zones.

ENERGY STAR certified cooling and heating for four independently controlled areas. This bundle includes four 12,000 BTU indoor units, with cold-climate heating down to -30 °C.

Down to -30 °CCold-weather heating
2,000-2,500 sq. ft.Recommended coverage
Four zonesIndependent comfort
ENERGY STARCertified efficiency

Performance at a Glance

23SEER2
11HSPF2-4
12EER2
-30 °CMinimum heating temperature
R454BRefrigerant
Senville AURA quad-zone mini split system with four indoor units and one outdoor unit
Cold-climate comfort

Heating Down to -30 °C

The AURA cold-climate heat pump is designed to continue providing heat at outdoor temperatures down to -30 °C (-22 °F).

Why Choose the SENA-48HF/Q?

Independent four-zone comfortFour indoor units connect to one outdoor unit, allowing settings to be adjusted separately for each served area. Four 12,000 BTU indoor unitsThis bundle pairs the outdoor unit with four wall-mounted indoor units rated at 12,000 BTU each. Have a professional confirm the sizing for every zone. Efficient cold-climate operationThe 23 SEER2 system is ENERGY STAR certified, offers up to 50% annual energy-cost savings and is designed to provide heating at -30 °C (-22 °F) with up to 75% efficiency (-22 °F).
Included with your system

Everything You Need to Get Started

Senville AURA multi-zone outdoor heat-pump unit
Outdoor unitSENA-48HF-MOA
Senville AURA wall-mounted indoor unit
Four indoor units12,000 BTU each
Senville AURA wireless remote control
Remote controls and Alexa kitWireless remotes plus USB kit
Insulated installation kit for a Senville mini split
Four installation kits16 ft. each or selected upgrades
Indoor-to-outdoor mini split wiring harness
Wiring harnessIndoor-to-outdoor connection
Four 16 ft. installation kits included
The product options also allow the included line-set lengths to be changed. Have the installer confirm the required length for every zone.
Pre-charged for up to 150 ft. total
The outdoor unit contains an R454B refrigerant pre-charge for a combined installation length of up to 150 ft.
Practical options

Complete Your Installation

Senville line set cover kit
OPTIONAL · SOLD SEPARATELY

Line set cover

Helps protect and conceal exposed refrigerant lines on the exterior of the building.

View accessories →
Large outdoor ground stand for a mini split condenser
OPTIONAL · SOLD SEPARATELY

Large outdoor ground stand

This stand is listed by Senville as a related option. Have the installer confirm the condenser footprint, weight and mounting requirements before purchase.

View ground stand →
Insulated refrigerant line set
SELECTABLE UPGRADE

25 ft. installation kits

Upgrade one, two, three or all four included 16 ft. kits to 25 ft. using the product options above. Have the installer confirm each zone's required length and any refrigerant adjustment.

View line sets →

Buy with Confidence

Manufacturer warranty

10 years on the compressor · 5 years on parts
Qualifying professional installation is required under the warranty terms.

Eligible for Tax Credit

Final eligibility depends on the purchaser, jurisdiction, applicable program requirements and the completed installation.

Professional installation required. The R454B system must be installed and commissioned by a professional with the qualifications required in the installation jurisdiction. Have the installer confirm line routing, drainage and electrical requirements for all four zones.
▶▼Technical Specifications+−
Model Number SENA-48HF-MOA
Style Ductless Mini Split AC With Heat Pump
Number of Zones 2-6
Power Supply (V-Ph-Hz) 208/230V, 1Ph, 60Hz
Voltage Range 187-253
SEER2 23
EER2 12
Cooling Capacity (BTU) 47000
Cooling Range (BTU) 12000~57000
Cooling Input Range (W) 800~5400
Cooling Current Range (A) 7~24
Heating Capacity (BTU) 49000
Heating Range (BTU) 13000~57000
Heating Input Range (W) 800~5200
Heating Current Range (A) 7~23
HSPF2-4 11
HSPF2-5 9
COP W/W 3.7
Minimum Circuit Ampacity (A) 37
Max. Fuse (A) 40
Outdoor Air Flow (Max) CFM 4502.8
Outdoor Noise Level dB 65
Outdoor Dimensions (WxDxH) (in.) 37.48 x 16.34 x 52.48
Outdoor Weight 246.47 Lbs
Minimum Outdoor Heating Temperature -22°F / -30°C
Refrigerant Type / Charge R454B / 151.68
Refrigerant Pre-charge 150 Ft.
Warranty 10 Years Compressor / 5 Years Parts

Frequently Asked Questions Before Purchase

▶▼What is included with this quad-zone bundle?+−

The bundle includes one SENA-48HF-MOA outdoor unit, four 12,000 BTU indoor units, wireless remote controls, the Alexa USB kit, four 16 ft. installation kits, an indoor-to-outdoor wiring harness and the manuals. Installation labor and building-specific materials are not included.

▶▼How cold can it be outside while heating?+−

The SENA-48HF/Q is designed to provide heating down to an outdoor temperature of -30 °C (-22 °F).

▶▼What indoor-unit configuration is included?+−

This listing includes four 12,000 BTU wall-mounted indoor units. Have a professional confirm that each indoor-unit capacity is appropriate for its room.

▶▼Can I install the system myself?+−

No. Professional installation is required for refrigerant handling, system commissioning and compliance with the warranty terms.

▶▼How does the warranty work?+−

The product page specifies 10 years of compressor coverage and five years of parts coverage, subject to Senville's installation, registration and maintenance conditions.
