18000 BTU Mini Split Air Conditioner - Heat Pump - SENA/18HF

$1,299.99
SKU:
SENA-18HF/Z
UPC:
893088008088
Share

Control the comfort of virtually any room or space with our high efficiency cold climate heat pumps. As part of our AURA Series, our wall mounted mini split air conditioners offer you efficient heating (up to -30C/-22F) and cooling, with up to 25 SEER and 10.3 HSPF on heating. Enjoy consistent climate control and comfort with minimal electrical consumption, thanks to our DC Inverter, variable speed compressor, with ENERGYSTAR Certification.


Key Product Features

  • 20 SEER (CEE Tier 2)
  • With Heat Pump (Up to -30C / -22F)
  • Energy Star Certified
  • Whisper Technology (Ultra Quiet)
  • Refrigerant Leak Detection
  • Inverter Technology
  • Silver Ion Filter (Anti-Microbial)
  • Vertical Swing Function
  • Built-In De-humidification Function
  • Follow Me Function (Remote with Built-In Thermostat)
  • Low Ambient Cooling (Up to -30C / -22F)
  • Self-Cleaning Mode
  • PTC Heat Belt and Pan
  • Bucket Free Outdoor Design
  • Self Diagnosis System

Documentation and Certifications

Technical Specifications

Senville Model # SENA/18HF
Power supply Ph-V-Hz 208-230V~  60Hz, 1Ph
Cooling Capacity                      Btu/h 17000
Input            W 1360
Rated current    A 5.95
EER         BTU/w 12.5
SEER BTU/w 20
Heating Capacity         Btu/h 18000
Input            W 1685
Rated current    A 7.4
COP W/W 3.13
HSPF4 BTU/w 10.3
HSPF5 BTU/w 8.8
Outdoor Operating Temp.   C/F -30/-22
MINIMUM  CIRCUIT  AMPACITY A 18
MAX.FUSE A 25
  Type    ROTARY
Brand    GMCC
Indoor Air Flow (High/Medium/Low) m3/h 950/750/600
Indoor Air Flow (High/Medium/Low) CFM 599/411/353
Indoor Noise Level (High/Medium/Low) dB(A) 45.5/36/26.5
Indoor unit Dimension (W*D*H) mm 990x218x315
Dimension (W*D*H) inch 38.98x8.58x12.40
Packing (W*D*H) mm 1065x300x400
Packing (W*D*H) inch 41.93x11.81x15.75
Net/Gross weight   kg 12.2/15.8
Net/Gross weight   lbs 26.89/34.83
Outdoor noise level         dB(A) 57.5
Outdoor unit Dimension(W*D*H) mm 845x363x702
Dimension(W*D*H) inch 33.27x14.29x27.64
Packing  (W*D*H) mm 965x395x755
Packing  (W*D*H) inch 37.99x15.55x29.72
Net/Gross weight   kg 48.7/52.2
Net/Gross weight   lbs. 107.4/115.1
Refrigerant Type g R410A/1950
Refrigerant Type oz R410A/68.8
Refrigerant Precharge ft 25
Additional Charge For Each ft oz 0.161
Refrigerant piping Liquid side/ Gas side   inch 1/4" & 1/2"
Max. refrigerant pipe length    m 30
Max. refrigerant pipe length    ft 98
Max. difference in level        m 20
Max. difference in level        ft 66
Connection wiring       16AWG*4  Stranded, unshielded
